Shenzhen Jingcheng Dingyi Forming Technology Co., Ltd. is one of the leading manufacturers and suppliers of custom mim components in China, specialized in providing high quality customized products. If you're going to buy bulk cheap custom mim components, welcome to get quotation from our factory. Quality products and low price are available.

Custom MIM Components

From Your CAD File to Production-Ready Metal Components

Start With the Part You Already Have

You do not need to redesign your component before contacting us.

We can work from:

• STEP / STP files
• 3D CAD models
• 2D engineering drawings
• Existing machined-part designs
• Prototype samples
• Assembly drawings
• Material specifications

If the current design was originally developed for CNC machining, casting, or another process, our engineering team can review whether modifications would make it more suitable for MIM.

What Happens After You Send the CAD?

01 - Engineering Review

We examine the geometry, dimensions, wall sections, holes, undercuts, draft requirements and other features that may affect tooling or molding.

The objective is simple:

Can this part be manufactured consistently?

02 - DFM Discussion

Before tooling starts, we discuss changes that may improve manufacturability.

This may involve:

• Adjusting wall sections
• Reviewing difficult features
• Considering draft
• Relocating gates or ejector areas
• Identifying critical dimensions
• Separating molded features from machined features
• Reviewing areas affected by sintering shrinkage

A good DFM review can prevent expensive tooling changes later. Design-for-manufacturing analysis is commonly used in injection-molded part development to identify difficult features before production.

Your Drawing Defines the Priorities

Not every dimension on a drawing has the same importance.

For a custom MIM component, we pay particular attention to CTQs - Critical to Quality features.

For example:

This allows the manufacturing plan to focus resources on the features that actually affect your product.

First Parts Are for Validation

The first molded components are not simply treated as the final production batch.

They give both sides an opportunity to verify:

• Overall geometry
• Critical dimensions
• Assembly fit
• Material requirements
• Surface condition
• Secondary machining
• Functional performance

If a feature needs adjustment, the design and tooling can be reviewed before moving into regular production.

This "DFM → tooling → first samples → approval → production" approach is also used by established custom molding services.

One Component, Different Production Stages

A typical custom project may develop through several stages:

CAD Design
↓
Engineering / DFM Review
↓
Tooling Design
↓
Mold Manufacturing
↓
Initial Parts
↓
Dimensional & Functional Inspection
↓
Design / Tool Adjustment if Required
↓
Production Release
↓
Repeat Orders

The exact route depends on your component, material, quantity and inspection requirements.

Already Have a CAD File?

You don't need to prepare a long technical brief before contacting us.

Send your CAD file + drawing + estimated quantity.

We can start by reviewing the component and discussing whether MIM is suitable, what design considerations should be addressed, and which features may require secondary machining.

Request a Custom MIM Review

Send Your CAD File → Discuss Your Component → Develop the Production Route
